Stumpjumper Expert Carbon 29

Stumpjumper Expert Carbon 29

Part No.: 93320-3303

Sold Out

Notify me when this product is available:

Color
Size

Select a Size

This is the bike that’s consistently reaped kudos from the cycling media and countless riders. Why all the accolades? Our asymmetric carbon chassis delivers a perfect blend of bump-devouring suspension and effortless control. Technically speaki... Read More

This is the bike that’s consistently reaped kudos from the cycling media and countless riders. Why all the accolades? Our asymmetric carbon chassis delivers a perfect blend of bump-devouring suspension and effortless control. Technically speaki... Read More

Stumpjumper Expert Carbon 29

₱287,595.00

×

This is the bike that’s consistently reaped kudos from the cycling media and countless riders. Why all the accolades? Our asymmetric carbon chassis delivers a perfect blend of bump-devouring suspension and effortless control. Technically speaking, this thing rips.

THE ULTIMATE TRAIL BIKE

The innovative sidearm frame design makes a lighter, better-handling bike. By directly connecting all three mounting points of the rear-end and shock to the frame, we’ve increased both stiffness and performance over bumps. End result? Total control.

LIGHTWEIGHT, CAPABLE…AND STUNNING

The Stumpjumper carbon chassis makes for one of the lightest, and yet most capable, trail bikes anywhere. The innovative frame melds smooth and deep suspension with smart features, including our integrated SWAT™ box downtube storage and hassle-free cable routing.

• Carbon frame is lightweight, stiff, and incredibly capable.

• FOX FLOAT DPX2 Performance rear shock is supple and easy to adjust on the fly.

• Roval Traverse Carbon wheels roll up to speed quickly and are bomb proof.

    This is the bike that’s consistently reaped kudos from the cycling media and countless riders. Why all the accolades? Our asymmetric carbon chassis delivers a perfect blend of bump-devouring suspension and effortless control. Technically speaking, this thing rips.

    THE ULTIMATE TRAIL BIKE

    The innovative sidearm frame design makes a lighter, better-handling bike. By directly connecting all three mounting points of the rear-end and shock to the frame, we’ve increased both stiffness and performance over bumps. End result? Total control.

    LIGHTWEIGHT, CAPABLE…AND STUNNING

    The Stumpjumper carbon chassis makes for one of the lightest, and yet most capable, trail bikes anywhere. The innovative frame melds smooth and deep suspension with smart features, including our integrated SWAT™ box downtube storage and hassle-free cable routing.

    • Carbon frame is lightweight, stiff, and incredibly capable.

    • FOX FLOAT DPX2 Performance rear shock is supple and easy to adjust on the fly.

    • Roval Traverse Carbon wheels roll up to speed quickly and are bomb proof.

      wishlist message

      Technical Specifications

      Saddle Bridge 155 S2, Bridge 143 S3/S4/S5, Hollow cr-mo rails
      Handlebars Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 780mm, 31.8mm clamp
      Grips Deity, Knuckleduster, Black
      SeatPost X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SRL LE lever, 34.9mm, S
      Stem Specialized Trail, forged alloy, 4-bolt, 5mm rise, 40mm
      Rear Shock FOX FLOAT DPX2 Performance, Rx Trail Tune, EVOL Air sleeve, 3-position adjustment, 210x50mm
      Shift Levers SRAM GX Eagle, trigger, 12-speed
      Rear Derailleur SRAM GX Eagle, 12-speed
      Cassette SRAM XG-1275 Eagle, 12-speed, 10-50t
      Bottom Bracket SRAM DUB, BSA 73mm, Threaded
      Chainrings Steel, 30T
      Crankset SRAM Descendant, Boost™, DUB, 170mm
      Chain SRAM GX Eagle, 12-speed
      Rear Tire Eliminator, GRID TRAIL casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
      Inner Tubes Standard, Presta valve
      Front Tire Butcher, GRID TRAIL casing, GRIPTON® compound, 2Bliss Ready, 29x2.6"
      Spokes DT Swiss Industry
      Front Hub Roval Traverse Carbon 29, hookless carbon, 30mm inner width, hand-built, 15x110mm spacing, 2Bliss Ready, 28h
      Rear Hub DT Swiss 370, 3-Pawl System, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
      Rims Roval Traverse Carbon 29, hookless carbon, 30mm inner width, hand-built, 2Bliss Ready
      Front Brake SRAM Code R, 4-piston caliper, hydraulic disc, 220mm
      Rear Brake SRAM Code R, 4-piston caliper, hydraulic disc, 180mm
      Pedals PEDAL, TEST RIDE PEDALS PROVIDED BY SPECIALIZED
      Frame FACT 11m, full carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 140mm of travel
      Seat Binder Specialized bolt-type, alloy, 38.6mm
      * Specifications are subject to change without notice

      Technical Specifications

      Saddle Bridge 155 S2, Bridge 143 S3/S4/S5, Hollow cr-mo rails
      Handlebars Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 780mm, 31.8mm clamp
      Grips Deity, Knuckleduster, Black
      SeatPost X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SRL LE lever, 34.9mm, S
      Stem Specialized Trail, forged alloy, 4-bolt, 5mm rise, 40mm
      Rear Shock FOX FLOAT DPX2 Performance, Rx Trail Tune, EVOL Air sleeve, 3-position adjustment, 210x50mm
      Shift Levers SRAM GX Eagle, trigger, 12-speed
      Rear Derailleur SRAM GX Eagle, 12-speed
      Cassette SRAM XG-1275 Eagle, 12-speed, 10-50t
      Bottom Bracket SRAM DUB, BSA 73mm, Threaded
      Chainrings Steel, 30T
      Crankset SRAM Descendant, Boost™, DUB, 170mm
      Chain SRAM GX Eagle, 12-speed
      Rear Tire Eliminator, GRID TRAIL casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
      Inner Tubes Standard, Presta valve
      Front Tire Butcher, GRID TRAIL casing, GRIPTON® compound, 2Bliss Ready, 29x2.6"
      Spokes DT Swiss Industry
      Front Hub Roval Traverse Carbon 29, hookless carbon, 30mm inner width, hand-built, 15x110mm spacing, 2Bliss Ready, 28h
      Rear Hub DT Swiss 370, 3-Pawl System, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
      Rims Roval Traverse Carbon 29, hookless carbon, 30mm inner width, hand-built, 2Bliss Ready
      Front Brake SRAM Code R, 4-piston caliper, hydraulic disc, 220mm
      Rear Brake SRAM Code R, 4-piston caliper, hydraulic disc, 180mm
      Pedals PEDAL, TEST RIDE PEDALS PROVIDED BY SPECIALIZED
      Frame FACT 11m, full carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 140mm of travel
      Seat Binder Specialized bolt-type, alloy, 38.6mm
      * Specifications are subject to change without notice

      Epic - Geometry

      Geometry

      S M L XL
        S M L XL
      Crank Length 170mm 170mm 170mm 17mmm
      Stem Length 40mm 40mm 50mm 50mm
      Handlebar Width 780mm 780mm 780mm 780mm
      Saddle Width 155mm 143mm 143mm 143mm
      Seatpost Length 375mm 438mm 438mm 478mm
      Stack 614mm 614mm 641mm 656mm
      Reach 405mm 425mm 445mm 470mm
      Head Tube Length 95mm 95mm 125mm 140mm
      Head Tube Angle 66.5deg 66.5deg 66.5deg 66.5deg
      BB Height 342mm 342mm 342mm 342mm
      BB Drop 33mm 33mm 33mm 33mm
      Trail 107mm 107mm 107mm 107mm
      Fork Length, Full 560mm 560mm 560mm 560mm
      Fork Rake/Offset 51mm 51mm 51mm 51mm
      Front Center 714mm 734mm 766mm 797mm
      Chainstay Length 437mm 437mm 437mm 437mm
      Wheelbase 1149mm 1169mm 1201mm 1232mm
      Top Tube Length, Horizontal 572mm 595mm 628mm 662mm
      Bike Standover Height 747mm 750mm 762mm 775mm
      Seat Tube Length 380mm 410mm 455mm 505mm
      Seat Tube Angle 74.8deg 74.5deg 74.1deg 73.7deg

      Geometry

      Geometry Chart

      Geometry

        S M L XL
      Crank Length 170mm 170mm 170mm 17mmm
      Stem Length 40mm 40mm 50mm 50mm
      Handlebar Width 780mm 780mm 780mm 780mm
      Saddle Width 155mm 143mm 143mm 143mm
      Seatpost Length 375mm 438mm 438mm 478mm
      Stack 614mm 614mm 641mm 656mm
      Reach 405mm 425mm 445mm 470mm
      Head Tube Length 95mm 95mm 125mm 140mm
      Head Tube Angle 66.5deg 66.5deg 66.5deg 66.5deg
      BB Height 342mm 342mm 342mm 342mm
      BB Drop 33mm 33mm 33mm 33mm
      Trail 107mm 107mm 107mm 107mm
      Fork Length, Full 560mm 560mm 560mm 560mm
      Fork Rake/Offset 51mm 51mm 51mm 51mm
      Front Center 714mm 734mm 766mm 797mm
      Chainstay Length 437mm 437mm 437mm 437mm
      Wheelbase 1149mm 1169mm 1201mm 1232mm
      Top Tube Length, Horizontal 572mm 595mm 628mm 662mm
      Bike Standover Height 747mm 750mm 762mm 775mm
      Seat Tube Length 380mm 410mm 455mm 505mm
      Seat Tube Angle 74.8deg 74.5deg 74.1deg 73.7deg

      Geometry

      Geometry Chart

      Stumpjumper Expert Carbon 29-Size Chart

      ×

      Trying to determine the best bike size for you? Not sure if your saddle height is set right? Retül is here to help. Find Your Size
