Stumpjumper Expert

Stumpjumper Expert

Part No.: 93321-3102

Notify me when this product is available:

Color
Size

Select a Size

With the all-new Stumpjumper Expert, we've bottled up that "new bike day" feeling and put it into a radical new trail bike so agile, so lively, so in-tune with the trail, that it feels like an extension of your body. Levitate up the climbs. Dec... Read More

With the all-new Stumpjumper Expert, we've bottled up that "new bike day" feeling and put it into a radical new trail bike so agile, so lively, so in-tune with the trail, that it feels like an extension of your body. Levitate up the climbs. Dec... Read More

wishlist message

Technical Specifications

SWAT SWAT™ Door integration
Seat Binder Alloy, 38.6
Frame FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, flip chip Head Tube/Bottom Bracket adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel
Chainrings 32T
Bottom Bracket SRAM DUB, BSA 73mm, threaded
Crankset SRAM Descendant 7K, DUB, S1
Chain SRAM GX Eagle, 12-speed
Shift Levers SRAM X01 Eagle, trigger, 12-speed
Cassette SRAM XG-1275, 12-speed, 10-52t
Rear Derailleur Sram X01 Eagle, 12-speed
Stem Alloy Trail Stem, 35mm bar bore
Saddle Bridge Comp, Hollow Cr-mo rails, 155/143mm
Grips Deity, Knuckleduster, Black
Handlebars Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 30mm rise, 800mm, 35mm clamp
SeatPost X-Fusion Manic, infinite adjustable, remote SRL LE lever, 34.9 (S1
Front Tire Butcher, GRID casing, GRIPTON® compound, 29x2.3"
Spokes DT Swiss Competition Race
Rear Tire Purgatory, GRID Casing, GRIPTON® compound, 29x2.3"
Rear Hub Roval DT Swiss 360, 3-pawl design, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
Rims Roval Traverse 29 Alloy, 30mm inner width, hand-built, 2Bliss Ready
Front Hub Roval, sealed cartridge bearings, 15x110mm spacing, 28h
Inner Tubes Standard, Presta valve
Fork FOX FLOAT 34 Performance Elite, GRIP2 damper, 15x110mm, 44mm offset, 140mm of travel
Rear Shock FOX FLOAT DPS Performance Elite, Rx Trail Tune, EVOL Air sleeve, 3-position adjustment w/ Open Mode Adjustment, 190x45mm
Rear Brake SRAM G2 RSC, 4-piston caliper, hydraulic disc, 180mm
Front Brake SRAM G2 RSC, 4-piston caliper, hydraulic disc, 200mm

Technical Specifications

SWAT SWAT™ Door integration
Seat Binder Alloy, 38.6
Frame FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, flip chip Head Tube/Bottom Bracket adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel
Chainrings 32T
Bottom Bracket SRAM DUB, BSA 73mm, threaded
Crankset SRAM Descendant 7K, DUB, S1
Chain SRAM GX Eagle, 12-speed
Shift Levers SRAM X01 Eagle, trigger, 12-speed
Cassette SRAM XG-1275, 12-speed, 10-52t
Rear Derailleur Sram X01 Eagle, 12-speed
Stem Alloy Trail Stem, 35mm bar bore
Saddle Bridge Comp, Hollow Cr-mo rails, 155/143mm
Grips Deity, Knuckleduster, Black
Handlebars Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 30mm rise, 800mm, 35mm clamp
SeatPost X-Fusion Manic, infinite adjustable, remote SRL LE lever, 34.9 (S1
Front Tire Butcher, GRID casing, GRIPTON® compound, 29x2.3"
Spokes DT Swiss Competition Race
Rear Tire Purgatory, GRID Casing, GRIPTON® compound, 29x2.3"
Rear Hub Roval DT Swiss 360, 3-pawl design, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
Rims Roval Traverse 29 Alloy, 30mm inner width, hand-built, 2Bliss Ready
Front Hub Roval, sealed cartridge bearings, 15x110mm spacing, 28h
Inner Tubes Standard, Presta valve
Fork FOX FLOAT 34 Performance Elite, GRIP2 damper, 15x110mm, 44mm offset, 140mm of travel
Rear Shock FOX FLOAT DPS Performance Elite, Rx Trail Tune, EVOL Air sleeve, 3-position adjustment w/ Open Mode Adjustment, 190x45mm
Rear Brake SRAM G2 RSC, 4-piston caliper, hydraulic disc, 180mm
Front Brake SRAM G2 RSC, 4-piston caliper, hydraulic disc, 200mm

Epic - Geometry

Geometry

  S1 S2 S3 S4 S5 S6
Crank Length 165mm 170mm 170mm 170mm 170mm 175mm
Stem Length 40mm 40mm 50mm 50mm 50mm 50mm
Handlebar Width 780mm 780mm 780mm 780mm 780mm 780mm
Saddle Width 155mm 155mm 143mm 143mm 143mm 143mm
Seatpost Length 100 mm 125 mm 150 mm 170mm 170 mm 190 mm
Stack (BB Basso) 614mm 613mm 622mm 632mm 641mm 650mm
Stack (BB Alto) 610mm 609mm 618mm 627mm 636mm 646mm
Reach (BB Basso) 410mm 430mm 450mm 475mm 500mm 530mm
Reach (BB Alto) 415mm 435mm 455mm 480mm 505mm 535mm
Lunghezza piantone 385mm 385mm 405mm 425mm 445mm 465mm
Angolo sterzo (BB Basso) 65deg 65deg 65deg 65deg 65deg 65deg
Angolo Sterzo (BB Alto) 65.5deg 65.5deg 65.5deg 65.5deg 65.5deg 65.5deg
Altezza BB (BB Basso) 328mm 333mm 333mm 333mm 333mm 333mm
Altezza BB (BB Alto) 335mm 340mm 340mm 340mm 340mm 340mm
BB Drop (BB Basso) 47mm 42mm 42mm 42mm 42mm 42mm
BB Drop (BB Alto) 40mm 35mm 35mm 35mm 35mm 35mm
Trail (BB Basso) 126mm 126mm 126mm 126mm 126mm 126mm
Trail (BB Alto) 123mm 123mm 123mm 123mm 123mm 123mm
Lunghezza Forcella 550mm 550mm 550mm 550mm 550mm 550mm
Offset Forcella/Rake 44mm 44mm 44mm 44mm 44mm 44mm
Avancorsa 724mm 746mm 770mm 800mm 829mm 863mm
Lunghezza Batticatena 432mm 432mm 432mm 432mm 442mm 442mm
Interasse 1152mm 1175mm 1200mm 1228mm 1268mm 1302mm
Lunghezza tubo orizz. virtuale 563mm 583mm 605mm 632mm 660mm 692mm
Altezza Standover 730mm 734mm 744mm 749mm 757mm 757mm
Angolo Sella (BB Basso) 76deg 76deg 76deg 76deg 76deg 76deg
Angolo Sella (BB Alto) 76.5deg 76.5deg 76.5deg 76.5deg 76.5deg 76.5deg
Max Inserimento Reggisella 220mm 220mm 240mm 260mm 280mm 300mm
Min Inserimento Reggisella 80mm 80mm 80mm 80mm 80mm 80mm

Geometry

Geometry Chart

Geometry

  S1 S2 S3 S4 S5 S6
Crank Length 165mm 170mm 170mm 170mm 170mm 175mm
Stem Length 40mm 40mm 50mm 50mm 50mm 50mm
Handlebar Width 780mm 780mm 780mm 780mm 780mm 780mm
Saddle Width 155mm 155mm 143mm 143mm 143mm 143mm
Seatpost Length 100 mm 125 mm 150 mm 170mm 170 mm 190 mm
Stack (BB Basso) 614mm 613mm 622mm 632mm 641mm 650mm
Stack (BB Alto) 610mm 609mm 618mm 627mm 636mm 646mm
Reach (BB Basso) 410mm 430mm 450mm 475mm 500mm 530mm
Reach (BB Alto) 415mm 435mm 455mm 480mm 505mm 535mm
Lunghezza piantone 385mm 385mm 405mm 425mm 445mm 465mm
Angolo sterzo (BB Basso) 65deg 65deg 65deg 65deg 65deg 65deg
Angolo Sterzo (BB Alto) 65.5deg 65.5deg 65.5deg 65.5deg 65.5deg 65.5deg
Altezza BB (BB Basso) 328mm 333mm 333mm 333mm 333mm 333mm
Altezza BB (BB Alto) 335mm 340mm 340mm 340mm 340mm 340mm
BB Drop (BB Basso) 47mm 42mm 42mm 42mm 42mm 42mm
BB Drop (BB Alto) 40mm 35mm 35mm 35mm 35mm 35mm
Trail (BB Basso) 126mm 126mm 126mm 126mm 126mm 126mm
Trail (BB Alto) 123mm 123mm 123mm 123mm 123mm 123mm
Lunghezza Forcella 550mm 550mm 550mm 550mm 550mm 550mm
Offset Forcella/Rake 44mm 44mm 44mm 44mm 44mm 44mm
Avancorsa 724mm 746mm 770mm 800mm 829mm 863mm
Lunghezza Batticatena 432mm 432mm 432mm 432mm 442mm 442mm
Interasse 1152mm 1175mm 1200mm 1228mm 1268mm 1302mm
Lunghezza tubo orizz. virtuale 563mm 583mm 605mm 632mm 660mm 692mm
Altezza Standover 730mm 734mm 744mm 749mm 757mm 757mm
Angolo Sella (BB Basso) 76deg 76deg 76deg 76deg 76deg 76deg
Angolo Sella (BB Alto) 76.5deg 76.5deg 76.5deg 76.5deg 76.5deg 76.5deg
Max Inserimento Reggisella 220mm 220mm 240mm 260mm 280mm 300mm
Min Inserimento Reggisella 80mm 80mm 80mm 80mm 80mm 80mm

Geometry

Geometry Chart
