Stumpjumper EVO Comp

Stumpjumper EVO Comp

Part No.: 96321-5001

Notify me when this product is available:

Color
Size

Select a Size

In order to bring EVO fun to the masses, we took our FACT 11m carbon frame (yes, the same one as the S-Works), dressed it with a bullet-proof Shimano SLX 12-speed drivetrain and a tough as nails set of alloy wheels, and set it loose to shred un... Read More

In order to bring EVO fun to the masses, we took our FACT 11m carbon frame (yes, the same one as the S-Works), dressed it with a bullet-proof Shimano SLX 12-speed drivetrain and a tough as nails set of alloy wheels, and set it loose to shred un... Read More

wishlist message

Technical Specifications

CRANKSET Shimano SLX, S1
CHAINRINGS 50/34T
CASSETTE Shimano SLX, CS-M7100, 12-speed, 10-51t
CHAIN Shimano SLX, M7100, 12-speed
SHIFT LEVERS Shimano SLX, M7100, 12spd
REAR DERAILLEUR Shimano SLX M7100, SGS, 12-speed
BOTTOM BRACKET Shimano, BB-MT800, Threaded
REAR SHOCK FOX FLOAT DPX2 Performance, Rx Trail Tune, EVOL Air sleeve, Kashima coat, 3-position adjustment, S1
FORK FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, S1
RIMS Roval 29, hookless alloy, 30mm inner width, tubeless ready
REAR TIRE Eliminator, GRID TRAIL casing, GRIPTON® compound, 29x2.3"
FRONT TIRE Butcher, GRID TRAIL casing, GRIPTON® compound, 29x2.3"
INNER TUBES Standard, Presta valve
FRONT HUB Shimano MT400-B, Centerlock 28h, 15x110 Boost
REAR HUB Shimano MT510-B, Centerlock 28h, 12x148 Boost, Microspline
SPOKES DT Swiss Industry
FRONT BRAKE Shimano SLX M7120, 4-piston caliper, hydraulic disc, 200mm
REAR BRAKE Shimano SLX M7120, 4-piston caliper, hydraulic disc, 180mm
STEM Alloy Trail Stem, 35mm bar bore
TAPE Specialized Trail Grips
HANDLEBARS Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm width
SEATPOST X-Fusion Manic, infinite adjustable, remote SRL LE lever, 34.9 (S1
SADDLE Bridge Comp, Hollow Cr-mo rails, 155/143mm
SEAT BINDER Alloy, 38.6
FRAME FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel
SWAT Increased-volume SWAT™ Door integration with 22oz SWAT™ Bladder

Technical Specifications

CRANKSET Shimano SLX, S1
CHAINRINGS 50/34T
CASSETTE Shimano SLX, CS-M7100, 12-speed, 10-51t
CHAIN Shimano SLX, M7100, 12-speed
SHIFT LEVERS Shimano SLX, M7100, 12spd
REAR DERAILLEUR Shimano SLX M7100, SGS, 12-speed
BOTTOM BRACKET Shimano, BB-MT800, Threaded
REAR SHOCK FOX FLOAT DPX2 Performance, Rx Trail Tune, EVOL Air sleeve, Kashima coat, 3-position adjustment, S1
FORK FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, S1
RIMS Roval 29, hookless alloy, 30mm inner width, tubeless ready
REAR TIRE Eliminator, GRID TRAIL casing, GRIPTON® compound, 29x2.3"
FRONT TIRE Butcher, GRID TRAIL casing, GRIPTON® compound, 29x2.3"
INNER TUBES Standard, Presta valve
FRONT HUB Shimano MT400-B, Centerlock 28h, 15x110 Boost
REAR HUB Shimano MT510-B, Centerlock 28h, 12x148 Boost, Microspline
SPOKES DT Swiss Industry
FRONT BRAKE Shimano SLX M7120, 4-piston caliper, hydraulic disc, 200mm
REAR BRAKE Shimano SLX M7120, 4-piston caliper, hydraulic disc, 180mm
STEM Alloy Trail Stem, 35mm bar bore
TAPE Specialized Trail Grips
HANDLEBARS Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm width
SEATPOST X-Fusion Manic, infinite adjustable, remote SRL LE lever, 34.9 (S1
SADDLE Bridge Comp, Hollow Cr-mo rails, 155/143mm
SEAT BINDER Alloy, 38.6
FRAME FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of travel
SWAT Increased-volume SWAT™ Door integration with 22oz SWAT™ Bladder

Epic - Geometry

Geometry

  S1 S3 S4 S6 S2 S5
Crank Length 165 170 170 175 170 170
Stem Length 40 50 50 50 40 50
Handlebar Width 800 800 800 800 800 800
Saddle Width 155 143 143 143 155 143
Seatpost Length 100 150 170 190 125 170

Geometry

Geometry Chart

Geometry

  S1 S3 S4 S6 S2 S5
Crank Length 165 170 170 175 170 170
Stem Length 40 50 50 50 40 50
Handlebar Width 800 800 800 800 800 800
Saddle Width 155 143 143 143 155 143
Seatpost Length 100 150 170 190 125 170

Geometry

Geometry Chart
