S-Works Venge

S-Works Venge

Part No.: 97819-0054

Color
Size

Select a Size

We aren"t satisfied with second fastest. Hell, why do you think we have our own Win Tunnel and the motto, "Aero is Everything?" We live and breathe aero, because we know that aerodynamic optimization is the best thing we can do to make you faster.... Read More
We aren"t satisfied with second fastest. Hell, why do you think we have our own Win Tunnel and the motto, "Aero is Everything?" We live and breathe aero, because we know that aerodynamic optimization is the best thing we can do to make you faster.... Read More

wishlist message

Technical Specifications

Frame S-Works FACT 11r carbon, Rider-First Engineered™, Win Tunnel Engineered, internal electric only cable routing, OSBB, 12x142mm thru-axle, flat-mount disc
Fork S-Works FACT 11r carbon, 100x12mm thru-axle, flat-mount disc
Handlebars S-Works Aerofly II, 80mm reach x 130mm drop
Stem Venge integrated stem, 6-degree
Tape S-Wrap Roubaix bar tape
Saddle S-Works Power, 143mm, carbon rails, carbon base, synthetic leather
SeatPost 2019 S-Works Venge aero seatpost, FACT carbon, Di2-compatible
Front Brake Shimano Dura-Ace R9170, hydraulic disc
Rear Brake Shimano Dura-Ace R9170, hydraulic disc
Shift Levers Shimano Dura-Ace Di2 Disc R9170
Front Derailleur Shimano Dura-Ace Di2 R9150, braze-on
Rear Derailleur Shimano Dura-Ace Di2 R9150, 11-speed
Cassette Shimano Dura-Ace 9100, 11-speed, 11-28t
Crankset S-Works Power Cranks, dual-sided power measurement, +/- 1.5% accuracy
Chainrings 52/36T
Bottom Bracket OSBB, CeramicSpeed bearings
Chain Shimano Dura-Ace, 11-speed
Front Wheel Roval CLX 64 Disc rim, Roval AFD1, Center Lock™, CeramicSpeed bearings, 21h
Rear Wheel Roval CLX 64 Disc, carbon, tubeless-ready, Win Tunnel Engineered, 64mm depth, DT Swiss 240 internals, CeramicSpeed bearings, 24h
Front Tire Turbo Cotton, 320 TPI, 700x26mm
Rear Tire Turbo Cotton, 320 TPI, 700x26mm

Technical Specifications

Frame S-Works FACT 11r carbon, Rider-First Engineered™, Win Tunnel Engineered, internal electric only cable routing, OSBB, 12x142mm thru-axle, flat-mount disc
Fork S-Works FACT 11r carbon, 100x12mm thru-axle, flat-mount disc
Handlebars S-Works Aerofly II, 80mm reach x 130mm drop
Stem Venge integrated stem, 6-degree
Tape S-Wrap Roubaix bar tape
Saddle S-Works Power, 143mm, carbon rails, carbon base, synthetic leather
SeatPost 2019 S-Works Venge aero seatpost, FACT carbon, Di2-compatible
Front Brake Shimano Dura-Ace R9170, hydraulic disc
Rear Brake Shimano Dura-Ace R9170, hydraulic disc
Shift Levers Shimano Dura-Ace Di2 Disc R9170
Front Derailleur Shimano Dura-Ace Di2 R9150, braze-on
Rear Derailleur Shimano Dura-Ace Di2 R9150, 11-speed
Cassette Shimano Dura-Ace 9100, 11-speed, 11-28t
Crankset S-Works Power Cranks, dual-sided power measurement, +/- 1.5% accuracy
Chainrings 52/36T
Bottom Bracket OSBB, CeramicSpeed bearings
Chain Shimano Dura-Ace, 11-speed
Front Wheel Roval CLX 64 Disc rim, Roval AFD1, Center Lock™, CeramicSpeed bearings, 21h
Rear Wheel Roval CLX 64 Disc, carbon, tubeless-ready, Win Tunnel Engineered, 64mm depth, DT Swiss 240 internals, CeramicSpeed bearings, 24h
Front Tire Turbo Cotton, 320 TPI, 700x26mm
Rear Tire Turbo Cotton, 320 TPI, 700x26mm

Epic - Geometry

Geometry

  49 52 54 56 58 61
Stack 504mm 517mm 534mm 555mm 581mm 602mm
Reach 378mm 383mm 387mm 398mm 405mm 411mm
Head-Tube Length 104mm 115mm 133mm 153mm 180mm 200mm
Head-Tube Angle 71.75deg 72.5deg 73deg 73.5deg 73.5deg 74deg
B-B Height 266mm 266mm 268mm 268mm 268mm 268mm
B-B Drop 74mm 74mm 72mm 72mm 72mm 72mm
Trail 63mm 58mm 58mm 55mm 55mm 52mm
Fork Length (Full) 363mm 363mm 363mm 363mm 363mm 363mm
Fork Rake/Offset 47mm 47mm 44mm 44mm 44mm 44mm
Front-Center 574mm 577mm 579mm 591mm 606mm 613mm
Chain-Stay Length 410mm 410mm 410mm 410mm 410mm 410mm
Wheelbase 972mm 975mm 978mm 991mm 1005mm 1012mm
Top-Tube Length (Horizontal) 508mm 531mm 540mm 562mm 577mm 595mm
Bike Stand-Over Height 736mm 756mm 773mm 795mm 817mm 841mm
Seat-Tube Length 455mm 480mm 495mm 518mm 537mm 567mm
Seat-Tube Angle 75.5deg 74deg 74deg 73.5deg 73.5deg 73deg

Geometry

Geometry Chart

Geometry

  49 52 54 56 58 61
Stack 504mm 517mm 534mm 555mm 581mm 602mm
Reach 378mm 383mm 387mm 398mm 405mm 411mm
Head-Tube Length 104mm 115mm 133mm 153mm 180mm 200mm
Head-Tube Angle 71.75deg 72.5deg 73deg 73.5deg 73.5deg 74deg
B-B Height 266mm 266mm 268mm 268mm 268mm 268mm
B-B Drop 74mm 74mm 72mm 72mm 72mm 72mm
Trail 63mm 58mm 58mm 55mm 55mm 52mm
Fork Length (Full) 363mm 363mm 363mm 363mm 363mm 363mm
Fork Rake/Offset 47mm 47mm 44mm 44mm 44mm 44mm
Front-Center 574mm 577mm 579mm 591mm 606mm 613mm
Chain-Stay Length 410mm 410mm 410mm 410mm 410mm 410mm
Wheelbase 972mm 975mm 978mm 991mm 1005mm 1012mm
Top-Tube Length (Horizontal) 508mm 531mm 540mm 562mm 577mm 595mm
Bike Stand-Over Height 736mm 756mm 773mm 795mm 817mm 841mm
Seat-Tube Length 455mm 480mm 495mm 518mm 537mm 567mm
Seat-Tube Angle 75.5deg 74deg 74deg 73.5deg 73.5deg 73deg

Geometry

Geometry Chart
