S-Works Aethos - SRAM Red eTap AXS

S-Works Aethos - SRAM Red eTap AXS

Part No.: 97221-0254

Notify me when this product is available:

Color
Size

Select a Size

For once, we’re not in it to win. With Aethos, we stopped worrying about winning, or the way things are supposed to be done, and instead chased the greatest expression of ride quality ever made. Well, we did it, and in staying true to keeping t... Read More

For once, we’re not in it to win. With Aethos, we stopped worrying about winning, or the way things are supposed to be done, and instead chased the greatest expression of ride quality ever made. Well, we did it, and in staying true to keeping t... Read More

wishlist message

Technical Specifications

Frame S-Works Aethos FACT 12r Carbon, Rider First Engineered™, Threaded BB, Electronic cable routing only, 12x142mm thru-axle, flat-mount disc
Fork S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Handlebars S-Works Short & Shallow
Stem S-Works SL, alloy, titanium bolts, 6-degree rise
Tape Supacaz Super Sticky Kush
Saddle Body Geometry S-Works Power, Carbon Fiber Rails, Carbon Fiber Base
SeatPost Roval Alpinist Carbon Seatpost
Seat Binder Specialized Alloy, 30.0mm, titanium bolt
Front Brake SRAM RED eTAP AXS, hydraulic disc
Rear Brake SRAM RED eTAP AXS, hydraulic disc
Front Derailleur SRAM RED eTAP AXS, braze-on
Rear Derailleur SRAM RED eTAP AXS, 12-speed
Cassette SRAM RED XG-1290, 12-speed, 10-33t
Crankset SRAM RED AXS Power Meter, 48/35T
Bottom Bracket SRAM DUB BSA 68
Chain SRAM RED, 12-speed
Front Wheel Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 21h, DT Swiss Aerolite spokes
Rear Wheel Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 24h, DT Swiss Aerolite spokes
Front Tire Turbo Cotton, 320 TPI, 700x26mm
Rear Tire Turbo Cotton, 320 TPI, 700x26mm
Inner Tubes Turbo Ultralight, 48mm Presta valve

Technical Specifications

Frame S-Works Aethos FACT 12r Carbon, Rider First Engineered™, Threaded BB, Electronic cable routing only, 12x142mm thru-axle, flat-mount disc
Fork S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
Handlebars S-Works Short & Shallow
Stem S-Works SL, alloy, titanium bolts, 6-degree rise
Tape Supacaz Super Sticky Kush
Saddle Body Geometry S-Works Power, Carbon Fiber Rails, Carbon Fiber Base
SeatPost Roval Alpinist Carbon Seatpost
Seat Binder Specialized Alloy, 30.0mm, titanium bolt
Front Brake SRAM RED eTAP AXS, hydraulic disc
Rear Brake SRAM RED eTAP AXS, hydraulic disc
Front Derailleur SRAM RED eTAP AXS, braze-on
Rear Derailleur SRAM RED eTAP AXS, 12-speed
Cassette SRAM RED XG-1290, 12-speed, 10-33t
Crankset SRAM RED AXS Power Meter, 48/35T
Bottom Bracket SRAM DUB BSA 68
Chain SRAM RED, 12-speed
Front Wheel Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 21h, DT Swiss Aerolite spokes
Rear Wheel Roval Alpinist CLX, 21mm internal width carbon rim, 33mm depth, Win Tunnel Engineered, Roval AFD hub, 24h, DT Swiss Aerolite spokes
Front Tire Turbo Cotton, 320 TPI, 700x26mm
Rear Tire Turbo Cotton, 320 TPI, 700x26mm
Inner Tubes Turbo Ultralight, 48mm Presta valve

Epic - Geometry

Geometry

  49 52 54 56 58 61
Crank Length 165mm 170mm 172.5mm 172.5mm 175mm 175mm
Handlebar Width 380mm 400mm 420mm 420mm 440mm 440mm
Stem Length 80mm 90mm 100mm 100mm 110mm 110mm
Saddle Width 155mm 155mm 143mm 143mm 143mm 143mm
Seatpost Length 300mm 300mm 360mm 360mm 360mm 360mm
Stack 514mm 527mm 544mm 565mm 591mm 612mm
Reach 375mm 380mm 384mm 395mm 402mm 408mm
Head Tube Length 109mm 120mm 137mm 157mm 184mm 204mm
Head Tube Angle 71.75deg 72.5deg 73deg 73.5deg 73.5deg 74deg
BB Height 266mm 266mm 268mm 268mm 268mm 268mm
BB Drop 74mm 74mm 72mm 72mm 72mm 72mm
Trail 63mm 58mm 58mm 55mm 55mm 52mm
Fork Length, Full 369mm 369mm 369mm 369mm 369mm 369mm
Fork Rake/Offset 47mm 47mm 44mm 44mm 44mm 44mm
Front Center 574mm 577mm 579mm 591mm 606mm 613mm
Chainstay Length 410mm 410mm 410mm 410mm 410mm 410mm
Wheelbase 973mm 975mm 978mm 991mm 1005mm 1012mm
Top Tube Length, Horizontal 508mm 531mm 540mm 562mm 577mm 595mm
Bike Standover Height 705mm 728mm 748mm 769mm 796mm 824mm
Seat Tube Length 431mm 462mm 481mm 504mm 532mm 567mm
Seat Tube Angle 75.5deg 74deg 74deg 73.5deg 73.5deg 73deg

Geometry

Geometry Chart

Geometry

  49 52 54 56 58 61
Crank Length 165mm 170mm 172.5mm 172.5mm 175mm 175mm
Handlebar Width 380mm 400mm 420mm 420mm 440mm 440mm
Stem Length 80mm 90mm 100mm 100mm 110mm 110mm
Saddle Width 155mm 155mm 143mm 143mm 143mm 143mm
Seatpost Length 300mm 300mm 360mm 360mm 360mm 360mm
Stack 514mm 527mm 544mm 565mm 591mm 612mm
Reach 375mm 380mm 384mm 395mm 402mm 408mm
Head Tube Length 109mm 120mm 137mm 157mm 184mm 204mm
Head Tube Angle 71.75deg 72.5deg 73deg 73.5deg 73.5deg 74deg
BB Height 266mm 266mm 268mm 268mm 268mm 268mm
BB Drop 74mm 74mm 72mm 72mm 72mm 72mm
Trail 63mm 58mm 58mm 55mm 55mm 52mm
Fork Length, Full 369mm 369mm 369mm 369mm 369mm 369mm
Fork Rake/Offset 47mm 47mm 44mm 44mm 44mm 44mm
Front Center 574mm 577mm 579mm 591mm 606mm 613mm
Chainstay Length 410mm 410mm 410mm 410mm 410mm 410mm
Wheelbase 973mm 975mm 978mm 991mm 1005mm 1012mm
Top Tube Length, Horizontal 508mm 531mm 540mm 562mm 577mm 595mm
Bike Standover Height 705mm 728mm 748mm 769mm 796mm 824mm
Seat Tube Length 431mm 462mm 481mm 504mm 532mm 567mm
Seat Tube Angle 75.5deg 74deg 74deg 73.5deg 73.5deg 73deg

Geometry

Geometry Chart
