Pitch 27.5

Part No. 95520-7102

Notify me when this product is available:

Color
Size
Size Chart
A mountain bike is freedom: the ability to pick a spot on the map and say, “Let’s go there,” or maybe go off the map altogether. With a lightweight frame, responsive front suspension, and powerful hydraulic disc brakes, the Pitch 27.5 is your perfect adventure partner. BEST OF BOTH WORLDS Riders have long debated whether fast-rolling 29er wheels were better than nimble 26ers. Turns out, the sweet spot for many is right in between, so the Pitch rolls on 27.5-inch wheels that keep much of a 29er’s confident handling in a tighter, lighter package. STRONG YET SMOOTH The A1 Premium Aluminum is burlier than a brontosaurus’s backbone. But strong doesn’t have to mean harsh or heavy. Our engineers went over every tube, tweaking, pinching, nipping and tucking to make sure it offers a smooth ride no matter what the trail conditions are. TOP TO BOTTOM QUALITY The Pitch’s sure-handling Sport Trail 27.5 Geometry provides unrivaled stability. SR SunTour XCE suspension fork keeps you grounded on the most technical trails. Shimano hydraulic disc brakes offer best-in-class power and reliability.
  • The best mountain bikes are the ones that let you tackle any terrain with confidence. The Pitch’s sure-handling Sport Trail 27.5 Geometry is designed for ultimate stability, whether you’re railing down a flowy singletrack or picking your way through a technical section.
  • Control means keeping those tires firmly planted. That’s where great suspension comes in, like the SR SunTour XCE 28 suspension fork on the Pitch, which features a coil spring for unparalleled small-bump responsiveness. Size-specific travel (80mm or 100mm) keeps geometry and handling consistent for riders of all sizes.
  • Braking isn’t just about power; it’s about how that power is used. The Shimano hydraulic disc brakes on the Pitch feature best-in-class modulation, so you can apply exactly the right amount of stopping power, without a death grip on the lever.

Technical Specifications

Frame A1 Premium Aluminum, Sport Trail 27.5 Geometry, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger
Fork SR SunTour XCE 28, Rx Tune, coil spring, 42mm offset, 80/100mm of travel (size-specific)
Stem Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebars Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Grips Specialized MTB Grip, lock-on
SeatPost Alloy, 12mm offset, 2-bolt clamp, 30.9mm
Front Brake Shimano BR-MT200, hydraulic disc
Rear Brake Shimano BR-MT200, hydraulic disc
Front Derailleur Shimano Tourney FD-TY710
Rear Derailleur Shimano Tourney TX, 8-speed
Shift Levers Shimano EF505, hydraulic, 2x8-speed
Cassette Sunrace, 8-speed, 11-34t
Chain KMC X8 EPT, anti-rust coating, 8-speed w/ reusable Missing Link™
Crankset Stout 2x, forged alloy
Chainrings 36/22T
Bottom Bracket Square-tapered, 73mm, internal bearings
Rims Stout Trail 27.5, alloy, disc-specific, double-wall, 25mm internal width, 32h
Front Hub Shimano, Center Lock™ disc, 9x100mm spacing, quick-release, 32h
Rear Hub Shimano FH-TX505, Center Lock™ disc, 9x135mm spacing, quick-release, 32h
Spokes Stainless, 14g
Front Tire Ground Control Sport, 60 TPI, wire bead, Flak Jacket Flat protection, 27.5 x 2.3\"
Rear Tire Ground Control Sport, 60 TPI, wire bead, Flak Jacket Flat protection, 27.5 x 2.3\"

Technical Specifications

Geometry

Geometry Chart

Geometry

  Size XS S M L XL
Stack 562mm 562mm 585mm 604mm 618mm
Reach 380mm 400mm 420mm 440mm 460mm
Head-Tube Length 95mm 95mm 100mm 120mm 135mm
Head-Tube Angle 68.5deg 68.5deg 68.5deg 68.5deg 68.5deg
B-B Height 310mm 310mm 310mm 310mm 310mm
B-B Drop 43mm 43mm 43mm 43mm 43mm
Trail 94mm 94mm 94mm 94mm 94mm
Fork Length (Full) 475mm 475mm 495mm 495mm 495mm
Fork Rake/Offset 42mm 42mm 42mm 42mm 42mm
Front-Center 631mm 651mm 680mm 708mm 733mm
Chain-Stay Length 435mm 435mm 435mm 435mm 435mm
Wheelbase 1063mm 1083mm 1112mm 1139mm 1165mm
Top-Tube Length (Horizontal) 542mm 572mm 599mm 625mm 649mm
Bike Stand-Over Height 660mm 690mm 739mm 766mm 808mm
Seat-Tube Length 310mm 360mm 415mm 450mm 510mm
Seat-Tube Angle 74deg 73deg 73deg 73deg 73deg

Geometry

Geometry Chart

Geometry
