Men's Epic Expert

Men's Epic Expert

Part No.: 90319-3102

Notify me when this product is available:

Color
Size

Select a Size

Lightweight carbon frame? Check. Industry-leading suspension technology? Oh yeah. Race-ready build kit? You know it. The Epic Expert is not only ready to shine in races, but it"s also ready to put your closest buddies in the pain cave on the weeke... Read More
Lightweight carbon frame? Check. Industry-leading suspension technology? Oh yeah. Race-ready build kit? You know it. The Epic Expert is not only ready to shine in races, but it"s also ready to put your closest buddies in the pain cave on the weeke... Read More

wishlist message

Technical Specifications

Frame Specialized FACT 11m, XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 100mm of travel
Fork RockShox SID Brain 29, Solo Air, Bottom-adjust Brain Fade, 15x110mm Maxle® Stealth thru-axle, 42mm offset, 100mm of travel
Rear Shock Custom RockShox Micro Brain shock w/ Spike Valve, AUTOSAG, 51x257mm
Handlebars Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Stem Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Grips Specialized Sip grip, half-waffle, S/M
Saddle Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
Seatpost Alloy, single-bolt, 30.9mm
Front Brake SRAM Level TL, hydraulic disc
Rear Brake SRAM Level TL, hydraulic disc
Shift Levers SRAM GX Eagle, trigger, 12-speed
Rear Derailleur SRAM GX Eagle, 12-speed
Cassette SRAM XG-1275 Eagle, 12-speed, 10-50t
Crankset Truvativ STYLO, DUB
Chainrings SRAM Eagle, 32T
Bottom Bracket SRAM DUB, BSA 73mm, Threaded
Chain SRAM GX Eagle, 12-speed
Rims Roval Control Carbon, 25mm internal width, tubeless-ready
Front Hub Specialized, sealed cartridge bearings, 15x110mm spacing, 28h
Rear Hub Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
Spokes DT Swiss Industry
Front Tire Fast Trak, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3\"
Rear Tire Fast Trak, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.1\"

Technical Specifications

Frame Specialized FACT 11m, XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 100mm of travel
Fork RockShox SID Brain 29, Solo Air, Bottom-adjust Brain Fade, 15x110mm Maxle® Stealth thru-axle, 42mm offset, 100mm of travel
Rear Shock Custom RockShox Micro Brain shock w/ Spike Valve, AUTOSAG, 51x257mm
Handlebars Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Stem Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Grips Specialized Sip grip, half-waffle, S/M
Saddle Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
Seatpost Alloy, single-bolt, 30.9mm
Front Brake SRAM Level TL, hydraulic disc
Rear Brake SRAM Level TL, hydraulic disc
Shift Levers SRAM GX Eagle, trigger, 12-speed
Rear Derailleur SRAM GX Eagle, 12-speed
Cassette SRAM XG-1275 Eagle, 12-speed, 10-50t
Crankset Truvativ STYLO, DUB
Chainrings SRAM Eagle, 32T
Bottom Bracket SRAM DUB, BSA 73mm, Threaded
Chain SRAM GX Eagle, 12-speed
Rims Roval Control Carbon, 25mm internal width, tubeless-ready
Front Hub Specialized, sealed cartridge bearings, 15x110mm spacing, 28h
Rear Hub Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
Spokes DT Swiss Industry
Front Tire Fast Trak, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3\"
Rear Tire Fast Trak, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.1\"

Epic - Geometry

Geometry

S M L XL
  S M L XL
Stack 588mm 597mm 611mm 630mm
Reach 408mm 433mm 456mm 475mm
Head-Tube Length 95mm 105mm 120mm 140mm
Head-Tube Angle 69.5deg 69.5deg 69.5deg 69.5deg
B-B Height 332mm 332mm 332mm 332mm
B-B Drop 38.9mm 38.9mm 38.9mm 38.9mm
Trail 94mm 94mm 94mm 94mm
Fork Length (Full) 506mm 506mm 506mm 506mm
Fork Rake/Offset 42mm 42mm 42mm 42mm
Front-Center 659mm 687mm 715mm 742mm
Chain-Stay Length 438mm 438mm 438mm 438mm
Wheelbase 1094mm 1123mm 1151mm 1177mm
Top-Tube Length (Horizontal) 568mm 596mm 623mm 647mm
Bike Stand-Over Height 764mm 770mm 776mm 799mm
Seat-Tube Length 400mm 434mm 470mm 520mm
Seat-Tube Angle 74.75deg 74.75deg 74.75deg 74.75deg

Geometry

Geometry Chart

Geometry

  S M L XL
Stack 588mm 597mm 611mm 630mm
Reach 408mm 433mm 456mm 475mm
Head-Tube Length 95mm 105mm 120mm 140mm
Head-Tube Angle 69.5deg 69.5deg 69.5deg 69.5deg
B-B Height 332mm 332mm 332mm 332mm
B-B Drop 38.9mm 38.9mm 38.9mm 38.9mm
Trail 94mm 94mm 94mm 94mm
Fork Length (Full) 506mm 506mm 506mm 506mm
Fork Rake/Offset 42mm 42mm 42mm 42mm
Front-Center 659mm 687mm 715mm 742mm
Chain-Stay Length 438mm 438mm 438mm 438mm
Wheelbase 1094mm 1123mm 1151mm 1177mm
Top-Tube Length (Horizontal) 568mm 596mm 623mm 647mm
Bike Stand-Over Height 764mm 770mm 776mm 799mm
Seat-Tube Length 400mm 434mm 470mm 520mm
Seat-Tube Angle 74.75deg 74.75deg 74.75deg 74.75deg

Geometry

Geometry Chart
