Epic Hardtail Expert

Epic Hardtail Expert

Part No.: 91319-3002

Notify me when this product is available:

Color
Size

Select a Size

With all of the growth in full-suspension XC bikes, we found that hardtails were starting to become a little same old, same old. So we thought to ourselves, "What better time then now to shake things up with a modern, revolutionary design?" Say he... Read More
With all of the growth in full-suspension XC bikes, we found that hardtails were starting to become a little same old, same old. So we thought to ourselves, "What better time then now to shake things up with a modern, revolutionary design?" Say he... Read More

wishlist message

Technical Specifications

Frame Specialized FACT 11m, XC Geometry, internal split-housing cable routing, PF30 BB, 12x148mm rear-end, triangulated post-mount 160mm brake
Fork RockShox SID 29 w/ Brain, bottom-adjust Brain Fade, 15x110mm Maxle® Stealth thru-axle, 51mm offset, (S
Handlebars Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Stem Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Grips Specialized Sip grip, half-waffle, S/M
Saddle Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
Seatpost Specialized, alloy, single-bolt, 27.2mm
Front Brake SRAM Level TL, hydraulic disc
Rear Brake SRAM Level TL, 2-piston caliper, hydraulic disc
Shift Levers SRAM GX Eagle, trigger, 12-speed
Rear Derailleur SRAM GX Eagle, 12-speed
Cassette SRAM XG-1275 Eagle, 12-speed, 10-50t
Crankset Truvativ STYLO, DUB
Chainrings SRAM Eagle, 32T
Bottom Bracket SRAM, DUB, PF30
Chain SRAM GX Eagle, 12-speed
Rims Roval Control Carbon, 25mm internal width, tubeless-ready
Front Hub Specialized, sealed cartridge bearings, 15x110mm spacing, 28h
Rear Hub Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
Spokes DT Swiss Industry
Front Tire Fast Trak, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3\"
Rear Tire Fast Trak, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.1\"

Technical Specifications

Frame Specialized FACT 11m, XC Geometry, internal split-housing cable routing, PF30 BB, 12x148mm rear-end, triangulated post-mount 160mm brake
Fork RockShox SID 29 w/ Brain, bottom-adjust Brain Fade, 15x110mm Maxle® Stealth thru-axle, 51mm offset, (S
Handlebars Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Stem Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Grips Specialized Sip grip, half-waffle, S/M
Saddle Body Geometry Phenom Comp, hollow Cr-Mo rails, 143mm
Seatpost Specialized, alloy, single-bolt, 27.2mm
Front Brake SRAM Level TL, hydraulic disc
Rear Brake SRAM Level TL, 2-piston caliper, hydraulic disc
Shift Levers SRAM GX Eagle, trigger, 12-speed
Rear Derailleur SRAM GX Eagle, 12-speed
Cassette SRAM XG-1275 Eagle, 12-speed, 10-50t
Crankset Truvativ STYLO, DUB
Chainrings SRAM Eagle, 32T
Bottom Bracket SRAM, DUB, PF30
Chain SRAM GX Eagle, 12-speed
Rims Roval Control Carbon, 25mm internal width, tubeless-ready
Front Hub Specialized, sealed cartridge bearings, 15x110mm spacing, 28h
Rear Hub Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
Spokes DT Swiss Industry
Front Tire Fast Trak, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3\"
Rear Tire Fast Trak, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.1\"

Epic - Geometry

Geometry

S M L XL
  S M L XL
Stack 599mm 608mm 622mm 637mm
Reach 395mm 418mm 441mm 462mm
Head-Tube Length 95mm 95mm 110mm 125mm
Head-Tube Angle 69.8deg 69.8deg 69.8deg 69.8deg
B-B Height 309mm 309mm 309mm 309mm
B-B Drop 61mm 61mm 61mm 61mm
Trail 82mm 82mm 82mm 82mm
Fork Length (Full) 496mm 506mm 506mm 506mm
Fork Rake/Offset 51mm 51mm 51mm 51mm
Front-Center 650mm 676mm 705mm 731mm
Chain-Stay Length 430mm 430mm 430mm 430mm
Wheelbase 1073mm 1099mm 1128mm 1154mm
Top-Tube Length (Horizontal) 568mm 595mm 623mm 649mm
Bike Stand-Over Height 760mm 790mm 814mm 845mm
Seat-Tube Length 400mm 430mm 470mm 520mm
Seat-Tube Angle 74deg 74deg 74deg 74deg

Geometry

Geometry Chart

Geometry

  S M L XL
Stack 599mm 608mm 622mm 637mm
Reach 395mm 418mm 441mm 462mm
Head-Tube Length 95mm 95mm 110mm 125mm
Head-Tube Angle 69.8deg 69.8deg 69.8deg 69.8deg
B-B Height 309mm 309mm 309mm 309mm
B-B Drop 61mm 61mm 61mm 61mm
Trail 82mm 82mm 82mm 82mm
Fork Length (Full) 496mm 506mm 506mm 506mm
Fork Rake/Offset 51mm 51mm 51mm 51mm
Front-Center 650mm 676mm 705mm 731mm
Chain-Stay Length 430mm 430mm 430mm 430mm
Wheelbase 1073mm 1099mm 1128mm 1154mm
Top-Tube Length (Horizontal) 568mm 595mm 623mm 649mm
Bike Stand-Over Height 760mm 790mm 814mm 845mm
Seat-Tube Length 400mm 430mm 470mm 520mm
Seat-Tube Angle 74deg 74deg 74deg 74deg

Geometry

Geometry Chart
