Epic Hardtail

Epic Hardtail

Part No.: 91320-7003

Notify me when this product is available:

Color
Size

Select a Size

Hands down, the best value in cross-country racing machines today. The Epic Hardtail now features the same featherweight carbon chassis as our Pro model. Complete with a smart component package and a ride quality that"s second to none, this bike i... Read More
Hands down, the best value in cross-country racing machines today. The Epic Hardtail now features the same featherweight carbon chassis as our Pro model. Complete with a smart component package and a ride quality that"s second to none, this bike i... Read More

wishlist message

Technical Specifications

Frame Specialized FACT 11m, XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing
SWAT SWAT EMT Cage-Mount Tool
Fork RockShox Judy Gold 29, Motion Control damper, 42mm offset, 15x110mm thru-axle, 100mm of travel
Stem Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Handlebars Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Grips Specialized Trail Grips
Saddle Body Geometry Power Sport, steel rails
SeatPost Specialized, alloy, single-bolt, 30.9mm
Front Brake Shimano MT-501, hydraulic disc, resin pad
Rear Brake Shimano MT-501, hydraulic disc, resin pad
Rear Derailleur SRAM NX Eagle, 12-speed
Shift Levers SRAM SX Eagle, trigger, 12-speed
Cassette SRAM PG-1210 Eagle, 11-50t
Chain SRAM SX Eagle, 12-speed
Crankset SRAM X1000 Eagle, DUB, 170/175mm
Chainrings Steel, 32T
Bottom Bracket SRAM DUB, BSA 73mm, Threaded
Rims Stout XC 29, 25mm internal width, disc-specific
Front Hub Specialized, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub Specialized, sealed cartridge bearings, 12x148mm thru-axle, 32h
Spokes DT Swiss Industry
Front Tire Fast Trak, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3\"
Rear Tire Fast Trak, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3\"

Technical Specifications

Frame Specialized FACT 11m, XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing
SWAT SWAT EMT Cage-Mount Tool
Fork RockShox Judy Gold 29, Motion Control damper, 42mm offset, 15x110mm thru-axle, 100mm of travel
Stem Specialized XC, 3D-forged alloy, 4-bolt, 6-degree rise
Handlebars Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp
Grips Specialized Trail Grips
Saddle Body Geometry Power Sport, steel rails
SeatPost Specialized, alloy, single-bolt, 30.9mm
Front Brake Shimano MT-501, hydraulic disc, resin pad
Rear Brake Shimano MT-501, hydraulic disc, resin pad
Rear Derailleur SRAM NX Eagle, 12-speed
Shift Levers SRAM SX Eagle, trigger, 12-speed
Cassette SRAM PG-1210 Eagle, 11-50t
Chain SRAM SX Eagle, 12-speed
Crankset SRAM X1000 Eagle, DUB, 170/175mm
Chainrings Steel, 32T
Bottom Bracket SRAM DUB, BSA 73mm, Threaded
Rims Stout XC 29, 25mm internal width, disc-specific
Front Hub Specialized, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub Specialized, sealed cartridge bearings, 12x148mm thru-axle, 32h
Spokes DT Swiss Industry
Front Tire Fast Trak, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3\"
Rear Tire Fast Trak, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3\"

Epic - Geometry

Geometry

XS S M L XL
  XS S M L XL
Stack 594mm 608mm 608mm 622mm 636mm
Reach 385mm 405mm 430mm 455mm 480mm
Head-Tube Length 95mm 95mm 95mm 110mm 125mm
Head-Tube Angle 68.5deg 68.5deg 68.5deg 68.5deg 68.5deg
B-B Height 309mm 309mm 309mm 309mm 309mm
B-B Drop 63mm 63mm 63mm 63mm 63mm
Trail 100mm 100mm 100mm 100mm 100mm
Fork Length (Full) 486mm 506mm 506mm 506mm 506mm
Fork Rake/Offset 42mm 42mm 42mm 42mm 42mm
Front-Center 642mm 669mm 694mm 724mm 754mm
Chain-Stay Length 430mm 430mm 430mm 430mm 430mm
Wheelbase 1063mm 1091mm 1116mm 1147mm 1177mm
Top-Tube Length (Horizontal) 555mm 579mm 604mm 633mm 662mm
Bike Stand-Over Height 732mm 762mm 792mm 816mm 847mm
Seat-Tube Length 367mm 400mm 430mm 470mm 520mm
Seat-Tube Angle 74deg 74deg 74deg 74deg 74deg
