Epic EVO Expert

Epic EVO Expert

Part No.: 94822-3001

Notify me when this product is available:

Color
Size

Select a Size

Looking for a bike that soars as well as it sprints? Look no further than the Epic EVO Expert.

Wheels up or head down, the Epic EVO Expert’s masterful blending of inspired handling, capable geometry and laser-focused pedaling efficiency m... Read More

Looking for a bike that soars as well as it sprints? Look no further than the Epic EVO Expert.

Wheels up or head down, the Epic EVO Expert’s masterful blending of inspired handling, capable geometry and laser-focused pedaling efficiency m... Read More

wishlist message

Technical Specifications

Frame FACT 11m Full Carbon, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 110mm of travel
SWAT SWAT EMT Cage-Mount Tool
Seat Binder Specialized Alloy, 34.9mm
Rear Shock RockShox SID LUXE Select+, Rx XC Tune, Two Position, Rebound Adjust, 190x40mm
Fork Rockshox SID Select+, Charger 2 RL Damper, Debon Air, 15x110mm, 44mm offset, 120mm Travel
Stem Alloy Trail Stem, 35mm bar bore
Handlebars Specialized Alloy, 20mm rise, 35mm, 760mm wide
Tape Specialized Trail Grips
Saddle Body Geometry Power Sport, steel rails
SeatPost X-Fusion Manic, 30.9, 100/125/150 Travel, 0mm offset
Front Brake SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Brake SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Derailleur Sram X01 Eagle, 12-speed
Shift Levers SRAM X01 Eagle, trigger, 12-speed
Cassette SRAM XG-1275, 12-speed, 10-52t
Chain SRAM GX Eagle, 12-speed
Crankset SRAM X1 Eagle Alloy, DUB, 165/170/175mm, 32t
Chainrings 32T
Bottom Bracket SRAM DUB, BSA 73mm, threaded
Rims Roval Control SL, Carbon offset design, 29mm internal width, 4mm hook width, Tubeless ready, 28h
Front Hub DT Swiss 350, 6-bolt, 15mm Thru-axle, 110mm spacing, 28h straight -pull
Rear Hub DT Swiss 350 straight-pull, 6-bolt, DT Swiss Ratchet EXP, 12x148mm thru axle, XD freehub body, 28h straight-pull
Spokes DT Swiss Comp Race
Front Tire Specialized Ground Control, Control Casing, T5 Compound, 29x2.35
Rear Tire Specialized Ground Control, Control Casing, T5 Compound, 29x2.35
Inner Tubes Standard, Presta valve

Technical Specifications

Frame FACT 11m Full Carbon, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 110mm of travel
SWAT SWAT EMT Cage-Mount Tool
Seat Binder Specialized Alloy, 34.9mm
Rear Shock RockShox SID LUXE Select+, Rx XC Tune, Two Position, Rebound Adjust, 190x40mm
Fork Rockshox SID Select+, Charger 2 RL Damper, Debon Air, 15x110mm, 44mm offset, 120mm Travel
Stem Alloy Trail Stem, 35mm bar bore
Handlebars Specialized Alloy, 20mm rise, 35mm, 760mm wide
Tape Specialized Trail Grips
Saddle Body Geometry Power Sport, steel rails
SeatPost X-Fusion Manic, 30.9, 100/125/150 Travel, 0mm offset
Front Brake SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Brake SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Derailleur Sram X01 Eagle, 12-speed
Shift Levers SRAM X01 Eagle, trigger, 12-speed
Cassette SRAM XG-1275, 12-speed, 10-52t
Chain SRAM GX Eagle, 12-speed
Crankset SRAM X1 Eagle Alloy, DUB, 165/170/175mm, 32t
Chainrings 32T
Bottom Bracket SRAM DUB, BSA 73mm, threaded
Rims Roval Control SL, Carbon offset design, 29mm internal width, 4mm hook width, Tubeless ready, 28h
Front Hub DT Swiss 350, 6-bolt, 15mm Thru-axle, 110mm spacing, 28h straight -pull
Rear Hub DT Swiss 350 straight-pull, 6-bolt, DT Swiss Ratchet EXP, 12x148mm thru axle, XD freehub body, 28h straight-pull
Spokes DT Swiss Comp Race
Front Tire Specialized Ground Control, Control Casing, T5 Compound, 29x2.35
Rear Tire Specialized Ground Control, Control Casing, T5 Compound, 29x2.35
Inner Tubes Standard, Presta valve

Epic - Geometry

Geometry

XS S M L XL
  XS S M L XL
Head Tube Angle 66.5deg 66.5deg 66.5deg 66.5deg 66.5deg
Wheelbase 1106mm 1132mm 1164mm 1194mm 1227mm
Reach 380mm 406mm 436mm 460mm 485mm
Fork Rake/Offset 44mm 44mm 44mm 44mm 44mm
Seat Tube Length 375mm 400mm 430mm 470mm 520mm
Trail 114mm 114mm 114mm 114mm 114mm
Fork Length, Full 530mm 530mm 530mm 530mm 530mm
Front Center 672mm 697mm 729mm 759mm 792mm
Bike Standover Height 760mm 779mm 781mm 793mm 804mm
Stack 603mm 593mm 597mm 611mm 629mm
BB Height 326mm 336mm 336mm 336mm 336mm
Chainstay Length 438mm 438mm 438mm 438mm 438mm
Top Tube Length, Horizontal 536mm 567mm 602mm 629mm 659mm
BB Drop 46mm 36mm 36mm 36mm 36mm
Seat Tube Angle 75.5deg 74.8deg 74.5deg 74.5deg 74.5deg
Head Tube Length 95mm 95mm 100mm 115mm 135mm
