Epic EVO Comp

Epic EVO Comp

Part No.: 94822-5202

Notify me when this product is available:

Color
Size

Select a Size

Lightweight yet stiff. Capable yet efficient. Fun yet focused. Hell, if Goldilocks ever wanted to drop you, our money’s on her picking an Epic EVO Comp to do the job.

While the Epic EVO sees a seemingly modest 20-millimeter increase in su... Read More

Lightweight yet stiff. Capable yet efficient. Fun yet focused. Hell, if Goldilocks ever wanted to drop you, our money’s on her picking an Epic EVO Comp to do the job.

While the Epic EVO sees a seemingly modest 20-millimeter increase in su... Read More

wishlist message

Technical Specifications

Frame FACT 11m Full Carbon, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 110mm of travel
SWAT SWAT EMT Cage-Mount Tool
Seat Binder Specialized Alloy, 34.9mm
Rear Shock RockShox Deluxe Select+, Rx XC Tune, Two Position, Rebound Adjust, 190x40mm
Fork Rockshox SID Select, Charger RL Damper, Debon Air, 15x110mm, 44mm offset, 120mm Travel
Stem Alloy Stem, 35mm clamp, 60mm
Handlebars Specialized Alloy, 20mm rise, 35mm, 760mm wide
Tape Specialized Trail Grips
Saddle Body Geometry Power Sport, steel rails
SeatPost X-Fusion Manic, 30.9, 125/150 Travel, 0mm offset
Front Brake SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Brake SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Derailleur SRAM GX Eagle, 12-speed
Shift Levers SRAM GX Eagle, 12-speed
Cassette SRAM XG-1275, 12-speed, 10-52t
Chain SRAM NX Eagle, 12-speed
Crankset SRAM, X1 Alloy Eagle, 12-speed
Chainrings 32T
Bottom Bracket SRAM DUB, BSA 73mm, threaded
Rims Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Front Hub Alloy, sealed cartridge bearings, 15x110mm thru-axle, 32h
Rear Hub Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h
Spokes DT Swiss Industry
Front Tire Ground Control, 2Bliss Ready, 29x2.35"
Rear Tire Ground Control, 2Bliss Ready, 29x2.35"
Inner Tubes Standard, Presta valve

Technical Specifications

Frame FACT 11m Full Carbon, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing, 110mm of travel
SWAT SWAT EMT Cage-Mount Tool
Seat Binder Specialized Alloy, 34.9mm
Rear Shock RockShox Deluxe Select+, Rx XC Tune, Two Position, Rebound Adjust, 190x40mm
Fork Rockshox SID Select, Charger RL Damper, Debon Air, 15x110mm, 44mm offset, 120mm Travel
Stem Alloy Stem, 35mm clamp, 60mm
Handlebars Specialized Alloy, 20mm rise, 35mm, 760mm wide
Tape Specialized Trail Grips
Saddle Body Geometry Power Sport, steel rails
SeatPost X-Fusion Manic, 30.9, 125/150 Travel, 0mm offset
Front Brake SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Brake SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm rotor
Rear Derailleur SRAM GX Eagle, 12-speed
Shift Levers SRAM GX Eagle, 12-speed
Cassette SRAM XG-1275, 12-speed, 10-52t
Chain SRAM NX Eagle, 12-speed
Crankset SRAM, X1 Alloy Eagle, 12-speed
Chainrings 32T
Bottom Bracket SRAM DUB, BSA 73mm, threaded
Rims Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Front Hub Alloy, sealed cartridge bearings, 15x110mm thru-axle, 32h
Rear Hub Alloy, sealed cartridge bearings, 148mmx12mm thru-axle, 28h
Spokes DT Swiss Industry
Front Tire Ground Control, 2Bliss Ready, 29x2.35"
Rear Tire Ground Control, 2Bliss Ready, 29x2.35"
Inner Tubes Standard, Presta valve

Epic - Geometry

Geometry

S M L XL
  S M L XL
Fork Length, Full 530mm 530mm 530mm 530mm
BB Drop 36mm 36mm 36mm 36mm
Front Center 697mm 729mm 759mm 792mm
Chainstay Length 438mm 438mm 438mm 438mm
Reach 406mm 436mm 460mm 485mm
Trail 114mm 114mm 114mm 114mm
Stack 593mm 597mm 611mm 629mm
Head Tube Length 95mm 100mm 115mm 135mm
Head Tube Angle 66.5deg 66.5deg 66.5deg 66.5deg
Fork Rake/Offset 44mm 44mm 44mm 44mm
Wheelbase 1132mm 1164mm 1194mm 1227mm
Seat Tube Angle 74.8deg 74.5deg 74.5deg 74.5deg
Seat Tube Length 400mm 430mm 470mm 520mm
BB Height 336mm 336mm 336mm 336mm
Bike Standover Height 779mm 781mm 793mm 804mm
Top Tube Length, Horizontal 567mm 602mm 629mm 659mm

Geometry

Geometry Chart

Geometry

  S M L XL
Fork Length, Full 530mm 530mm 530mm 530mm
BB Drop 36mm 36mm 36mm 36mm
Front Center 697mm 729mm 759mm 792mm
Chainstay Length 438mm 438mm 438mm 438mm
Reach 406mm 436mm 460mm 485mm
Trail 114mm 114mm 114mm 114mm
Stack 593mm 597mm 611mm 629mm
Head Tube Length 95mm 100mm 115mm 135mm
Head Tube Angle 66.5deg 66.5deg 66.5deg 66.5deg
Fork Rake/Offset 44mm 44mm 44mm 44mm
Wheelbase 1132mm 1164mm 1194mm 1227mm
Seat Tube Angle 74.8deg 74.5deg 74.5deg 74.5deg
Seat Tube Length 400mm 430mm 470mm 520mm
BB Height 336mm 336mm 336mm 336mm
Bike Standover Height 779mm 781mm 793mm 804mm
Top Tube Length, Horizontal 567mm 602mm 629mm 659mm

Geometry

Geometry Chart
