Allez Sprint Comp

Allez Sprint Comp

Part No.: 90019-5049

Notify me when this product is available:

Color
Size

Select a Size

Climbs, corners, flat-out sprints—the Allez Sprint Comp does it all. Being the most advanced alloy road bike we"ve ever made, the Allez Sprint is capable as a crit-racing weapon or an everyday road steed. But even better, it performs all of the ab... Read More
Climbs, corners, flat-out sprints—the Allez Sprint Comp does it all. Being the most advanced alloy road bike we"ve ever made, the Allez Sprint is capable as a crit-racing weapon or an everyday road steed. But even better, it performs all of the ab... Read More

wishlist message

Technical Specifications

Frame Specialized E5 Premium Aluminum w/ D\'Aluisio Smartweld Sprint Technology, hydroformed aluminum tubing, tapered head tube, OSBB
Fork S-Works FACT full carbon, size-specific taper
Handlebars Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp
Stem Specialized, 3D-forged alloy, 4-bolt, 6-degree rise
Tape Specialized S-Wrap
Saddle Body Geometry Toupé Sport, steel rails, 143mm
SeatPost Specialized Venge Aero seatpost, FACT carbon
Front Brake Shimano 105 R7000
Rear Brake Shimano 105 R7000
Shift Levers Shimano 105 R7000, 11-speed
Front Derailleur Shimano 105 R7000, 11-speed, clamp-on
Rear Derailleur Shimano 105 R7000 GS, medium cage, 11-speed
Cassette Shimano R7000, 11-speed, 11-28t
Crankset Praxis Zayante, BB30
Chainrings 52/36T
Bottom Bracket Praxis 6806 bearings
Chain KMC X11 EL, 11-speed w/ Missing Link™
Front Wheel DT R460, sealed cartridge hubs, 14g spokes, 20h
Rear Wheel DT R460, sealed cartridge hubs, 14g spokes, 24h
Front Tire Turbo Pro, 60 TPI, folding bead, BlackBelt protection, 700x26mm
Rear Tire Turbo Pro, 60 TPI, folding bead, BlackBelt protection, 700x26mm

Technical Specifications

Frame Specialized E5 Premium Aluminum w/ D\'Aluisio Smartweld Sprint Technology, hydroformed aluminum tubing, tapered head tube, OSBB
Fork S-Works FACT full carbon, size-specific taper
Handlebars Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp
Stem Specialized, 3D-forged alloy, 4-bolt, 6-degree rise
Tape Specialized S-Wrap
Saddle Body Geometry Toupé Sport, steel rails, 143mm
SeatPost Specialized Venge Aero seatpost, FACT carbon
Front Brake Shimano 105 R7000
Rear Brake Shimano 105 R7000
Shift Levers Shimano 105 R7000, 11-speed
Front Derailleur Shimano 105 R7000, 11-speed, clamp-on
Rear Derailleur Shimano 105 R7000 GS, medium cage, 11-speed
Cassette Shimano R7000, 11-speed, 11-28t
Crankset Praxis Zayante, BB30
Chainrings 52/36T
Bottom Bracket Praxis 6806 bearings
Chain KMC X11 EL, 11-speed w/ Missing Link™
Front Wheel DT R460, sealed cartridge hubs, 14g spokes, 20h
Rear Wheel DT R460, sealed cartridge hubs, 14g spokes, 24h
Front Tire Turbo Pro, 60 TPI, folding bead, BlackBelt protection, 700x26mm
Rear Tire Turbo Pro, 60 TPI, folding bead, BlackBelt protection, 700x26mm

Epic - Geometry

Geometry

  49 52 54 56 58 61
Stack 502mm 514mm 533mm 554mm 583mm 604mm
Reach 375mm 380mm 385mm 395mm 400mm 405mm
Head-Tube Length 100mm 110mm 130mm 150mm 180mm 200mm
Head-Tube Angle 72.25deg 73deg 73deg 73.5deg 73.5deg 74deg
B-B Height 272.5mm 272.5mm 272.5mm 272.5mm 272.5mm 272.5mm
B-B Drop 69mm 69mm 69mm 69mm 69mm 69mm
Trail 63mm 58mm 58mm 55mm 55mm 52mm
Fork Length (Full) 368mm 368mm 368mm 368mm 368mm 368mm
Fork Rake/Offset 44mm 44mm 44mm 44mm 44mm 44mm
Front-Center 564mm 566mm 577mm 589mm 602mm 608mm
Chain-Stay Length 405mm 405mm 405mm 405mm 405mm 407mm
Wheelbase 959mm 961mm 972mm 984mm 997mm 1005mm
Top-Tube Length (Horizontal) 519mm 527mm 538mm 554mm 567mm 578mm
Bike Stand-Over Height 732.3mm 745.8mm 765.5mm 784.3mm 808.3mm 833.8mm
Seat-Tube Length 460mm 480mm 500mm 520mm 540mm 570mm
Seat-Tube Angle 74deg 74deg 74deg 74deg 74deg 74deg

Geometry

Geometry Chart

Geometry

  49 52 54 56 58 61
Stack 502mm 514mm 533mm 554mm 583mm 604mm
Reach 375mm 380mm 385mm 395mm 400mm 405mm
Head-Tube Length 100mm 110mm 130mm 150mm 180mm 200mm
Head-Tube Angle 72.25deg 73deg 73deg 73.5deg 73.5deg 74deg
B-B Height 272.5mm 272.5mm 272.5mm 272.5mm 272.5mm 272.5mm
B-B Drop 69mm 69mm 69mm 69mm 69mm 69mm
Trail 63mm 58mm 58mm 55mm 55mm 52mm
Fork Length (Full) 368mm 368mm 368mm 368mm 368mm 368mm
Fork Rake/Offset 44mm 44mm 44mm 44mm 44mm 44mm
Front-Center 564mm 566mm 577mm 589mm 602mm 608mm
Chain-Stay Length 405mm 405mm 405mm 405mm 405mm 407mm
Wheelbase 959mm 961mm 972mm 984mm 997mm 1005mm
Top-Tube Length (Horizontal) 519mm 527mm 538mm 554mm 567mm 578mm
Bike Stand-Over Height 732.3mm 745.8mm 765.5mm 784.3mm 808.3mm 833.8mm
Seat-Tube Length 460mm 480mm 500mm 520mm 540mm 570mm
Seat-Tube Angle 74deg 74deg 74deg 74deg 74deg 74deg

Geometry

Geometry Chart
